Madone SLR 9 Disc eTap pairs the aerodynamics and ride quality of an all-new 800 Series OCLV Carbon frame with the smoothness of SRAM's most advanced electronic drivetrain, RED eTap AXS. It's the first-ever wireless electronic groupset with a 12-speed cassette. Saddle up for the quickest and smartest shifting of your life.
It's right for you if...
You want every advantage in speed and handling, and want a bike with the best tech available: our best-ever Madone frame, a SRAM RED AXS power meter, and a top-of-the-line, 12-speed SRAM RED eTap AXS wireless electronic drivetrain that shifts with crisp precision.
The tech you get
Our lightest-ever 800 Series OCLV Carbon frame with Kammtail Virtual Foil aerodynamic tube shaping and road-smoothing Adjustable Top Tube IsoSpeed, KVF full carbon fork, an adjustable aero bar and stem, a 2x12 SRAM RED eTap AXS wireless electronic drivetrain, Tubeless Ready Bontrager Aeolus XXX 6 wheels, a micro-adjust Madone seatmast, and RED flat-mount hydraulic disc brakes.
The final word
Madone at it's finest. You get the most advanced aero carbon frame we've ever made, aero components, and a 12-speed SRAM RED eTap AXS electronic drivetrain and power meter. It's eTap evolved to be smoother and more intuitive, and you can personalize every setting using the AXS app.
Why you'll love it
- 800 Series OCLV Carbon is the lightest laminate we’ve ever made, and it makes Madone faster on any terrain, in any conditions
- Comes with a SRAM Red AXS power meter for more effective training rides from the start
- Adjustable Top Tube IsoSpeed lets you adjust compliance to your preference, and it's damped with an elastomer so it rebounds in a smooth, controlled, stable motion
- A separate bar and stem with an aero carbon faceplate gives you great adjustability without compromising on aerodynamics
- Madone Project One ICON paint schemes make the ultimate race bike a true piece of artwork
Electronic drivetrain systems deliver excellent shifting, easy set up, and solid battery life. Here are the highlights of today’s electronic shifting systems:
Electronic shifting systems use powerful servomotors to rapidly shift the chain. Because microprocessors and sensors constantly monitor every aspect of the system, they shift with precisely and without chain rub.
Many major systems have customizable shifting. Some have the ability to add remote shifters for common riding positions, and some even allow you to change the functions of the shifting buttons.
Electronic groupsets are responsive and consistent. There are no cables to stretch and wear out, so you get a flawless shift every time. The added bonus is you’ll never have to replace a derailleur cable ever again.
Pedals sold separately
Due to supply-chain issues, Specs are subject to change without notice.
|Frame||800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, DuoTrap S compatible, flat mount disc|
|Fork||Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat mount disc, carbon dropouts|
Front: 100 x 12mm thru axle
Rear: 142 x 12mm thru axle
Front: Bontrager Aeolus XXX 6, OCLV Carbon, Tubeless Ready, 21mm rim width, 60mm rim depth
Rear: Bontrager Aeolus XXX 6, OCLV Carbon, Tubeless Ready, 21mm rim width, 60mm rim depth, SRAM XD-R driver
|Tires||Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700 x 25c|
|Crankset||SRAM RED AXS Power Meter, 48/35, DUB spindle|
|Bottom Bracket||SRAM DUB, T47 threaded, internal bearing|
|Chain||SRAM RED D1, 12 speed|
|Front Derailleur||SRAM RED eTap AXS, braze-on|
|Rear Derailleur||SRAM RED eTap AXS, Orbit chain management|
|Cassette/Rear Cogs||SRAM RED XG-1290, 10-33, 12 speed|
|Shifters||SRAM RED eTap AXS, 12 speed|
|Handlebars||Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93mm reach, 123mm drop|
|Tape/Grips||Bontrager Supertack Perf tape|
|Stem||Trek Madone aero, invisible cable routing, 7 degree|
|Brakes||SRAM Red eTap AXS hydraulic disc, flat mount|
|Saddle||Bontrager Aeolus Pro, carbon rails, 145mm width|
|Seat Post||Madone aero carbon internal seatmast cap, integrated light mount, 25mm offset|
* Subject to change without notice.
|Matte Onyx Carbon / 52cm||601842441022||1049834||MAD32801241N|
|Matte Onyx Carbon / 56cm||601842441008||1049836||MAD32472489N|
